Labotemp Laboratory Muffle Furnaces provide rapid high-temperature heating, fast recovery, and efficient cooling in compact, energy-efficient cabinets designed for laboratory and industrial use, making Labotemp a trusted choice among muffle furnace manufacturers. These electric muffle furnaces feature digital PID temperature control, uniform four-sided heating, and highly insulated aluminum silicate or mullite fiber chambers to achieve maximum thermal efficiency. Available in multiple chamber sizes and temperature ranges up to 1700 °C, Labotemp lab muffle furnaces are ideal for ashing, heat treatment, calcination, sintering, and advanced materials research. Their robust construction, precise temperature stability, and fast heat-up performance make them a reliable solution for laboratories, research institutes, and industrial quality-control applications. As an experienced furnace manufacturer and laboratory furnace supplier, Labotemp delivers high-efficiency furnaces engineered for accuracy, durability, and repeatable results.
Al-Silicate Body
Maximum Temperature : 1000°C
Chamber Volume : 2 L
Rated Power : 2.5 kW
Time from Room Temp. to Max Temp. (min) : 60
Digital PID Control
Maximum Temperature : 1000°C
Chamber Volume : 7L
Rated Power : 4 kW
Time from Room Temp. to Max Temp. (min) : 70
Oxidation-Free
Maximum Temperature : 1000°C
Chamber Volume : 16 L
Rated Power : 8 kW
Time from Room Temp. to Max Temp. (min) : 75
Energy Efficient
Equipment Type : Box-type muffle furnace
Maximum Operating Temperature : 1000°C
Maximum Allowable Temperature : 1100°C
Internal Chamber Volume : 16 liters
Auto Safety Shutdown
Capacity : 7 L
Temperature Control Range : 300–1000°C
Power Supply : AC220V 50Hz
Temperature Control Accuracy : ±5°C
1200°C Performance
Maximum Temperature : 1200°C
Chamber Volume : 2L
Rated Power : 2.5 kW
Time from Room Temp. to Max Temp. (min) : 80
Alloy Heating Wire
Maximum Temperature : 1200°C
Chamber Volume : 7 L
Rated Power : 5 kW
Time from Room Temp. to Max Temp. (min) : 80
Accurate Monitoring
Maximum Temperature : 1200°C
Chamber Volume : 16 L
Rated Power : 10 kW
Time from Room Temp. to Max Temp. (min) : 80
Uniform Heat Control
Capacity : 12 L
Temperature Range : 100°C – 1200°C
Temperature Resolution : 1°C
Temperature Accuracy : ±1°C
Safe-Touch Steel Body
Capacity : 40 Liters
Maximum Temperature : 1200°C
Continuous Working Temperature : 1100°C
Minimum Temperature : Ambient
Type-N thermocouple
Furnace Type : Muffle Furnace (Benchtop)
Heating Element : HRE Heating Wire
Thermocouple : Type N
Chamber Material : High-alumina 1500# ceramic fiber board
1600°C High Range
Model NO. : FMU-07
Volume : 4L
Temperature Range : 1600℃ (1500℃ continuous)
Temperature Resolution : 1℃
LED Display
Model NO. : FMU-08
Volume : 12L
Temperature Range : 1600℃ (1500℃ continuous)
Temperature Resolution : 1℃
Al-Silicate Body
Model NO. : FMU-09
Volume : 20 L
Temperature Range : 1600℃ (1500℃ continuous)
Temperature Resolution : 1℃
36L Large Capacity
Model NO. : FMU-10
Volume : 36 L
Temperature Range : 1600℃ (1500℃ continuous)
Temperature Resolution : 1℃
1700°C Peak Temp
Model NO. : FMU-11
Volume : 4 L
Temperature Range : 1700℃
Temperature Resolution : 1℃
1700℃ Control
Model NO. : FMU-12
Volume : 12 L
Temperature Range : 1700℃
Temperature Resolution : 1℃
Superior Insulation
Model NO. : FMU-13
Volume : 20 L
Temperature Range : 1700℃
Temperature Resolution : 1℃
Sintering Ready
Model NO. : FMU-14
Volume : 36 L
Temperature Range : 1700℃
Temperature Resolution : 1℃
Advanced Safety Protection
Capacity : 6.7 L
Temperature Range : 1700°C
Power Supply : AC220V / 50Hz
Heating Power : 9 kW
50-Segment PID Control
Maximum Temperature : 1700 °C
Continuous Operating Temperature : ≤ 1600 °C
Heating Element : Premium 1800-grade MoSi₂ (Silicon Molybdenum) Rods
Temperature Sensor : B-Type Thermocouple
8L Compact Chamber
Maximum Temperature : 1700 °C
Continuous Operating Temperature : ≤ 1600 °C
Heating Element : Premium 1800-grade MoSi₂ (Silicon Molybdenum) Rods
Temperature Sensor : B-Type Thermocouple
Compact Design
Maximum temperature : 1200 ℃
Common operating temperature : < 1100 ℃
Voltage : AC 220V, 50HZ
Power : 1 kW
Inert Gas System
Maximum temperature : 1200 ℃
Common operating temperature : < 1100 ℃
Voltage : AC 220V, 50HZ
Power : 3kw
Over Temperature Warning
Maximum Temperature : 1200 ℃
Common operating temperature : < 1100 ℃
Voltage : AC 220V, 50HZ
Power : 6 kW
Digital Display
Maximum Temperature : 1200 ℃
Common operating temperature : < 1100 ℃
Voltage : AC 220V, 50HZ
Power : 9 kW
Real-Time Monitoring
Maximum Temperature : 800°C
Standard Working Temperature : 538°C
Balance Capacity : 12 kg
Power Supply : AC 380V 50Hz ±10V, 15A
±0.11% Test Accuracy
Operating Temperature Range : 200°C – 650°C
Default Operating Temperature : 538°C
Power Supply : 220–240 V, 60 Hz, 20/27 A
Afterburner Temperature Range : 650°C – 750°C
