Labotemp Automatic Vertical Steam Sterilizer VEA-05 is a large 75 liter vertical autoclave engineered for laboratories, pharmaceutical quality control units, and hospital departments requiring advanced steam sterilization with enhanced penetration. Equipped with three-time pre-vacuum technology, this autoclave sterilizer effectively removes trapped air before steam injection, ensuring reliable sterilization of wrapped instruments, surgical packs, glassware, and laboratory tools. It operates within a temperature range of 116°C to 134°C at a rated working pressure of 0.22 MPa, delivering stable thermal performance supported by a 4.5 kW heating system for consistent and repeatable cycles.
This model integrates microcomputer automatic control with an LED touch screen for precise parameter adjustment and monitoring. Features such as automatic water supply, external steam generator, automatic cold air discharge, and steam exhaust improve efficiency while reducing operator workload. Safety interlocking device, over-temperature protection, over-pressure self-discharge, and low water level safeguards ensure secure operation in demanding laboratory environments.
Why Choose Labotemp Vertical Autoclave VEA-05?
✓ Advanced Manufacturing: Built with precision-engineered components and durable stainless steel chamber for long-term operational reliability
✓ Certified Compliance: Manufactured under ISO quality systems and CE certified standards for safety and regulatory confidence
✓ Enhanced Sterilization Assurance: Three-time pre-vacuum technology for dependable processing of wrapped and critical loads
| General Specifications | |
|
Volume : 75 L Volume |
75 L |
|
Working Temperature : 134°C Working Temperature |
134°C |
|
Power : 4.5 kW Power |
4.5 kW |
|
Voltage : AC 220 V, 50 Hz Voltage |
AC 220 V, 50 Hz |
| Sterilization Parameters | |
|
Design Temperature : 139°C Design Temperature |
139°C |
|
Sterilization Temperature Range : 116–134°C Sterilization Temperature Range |
116–134°C |
|
Design Pressure : 0.25 MPa Design Pressure |
0.25 MPa |
|
Rated Working Pressure : 0.22 MPa Rated Working Pressure |
0.22 MPa |
| Chamber Dimensions | |
|
Chamber Size (mm) : 400 × 655 Chamber Size (mm) |
400 × 655 |
|
Bucket Dimension (mm) : 380 × 560 Bucket Dimension (mm) |
380 × 560 |
|
Basket Dimension (mm) : 360 × 280 × 2 Basket Dimension (mm) |
360 × 280 × 2 |
| Operation | |
|
Air Removal : Vacuum pump Air Removal |
Vacuum pump |
|
Automatic Water Filling : Automatic water (standard) Automatic Water Filling |
Automatic water (standard) |
| Physical Dimensions | |
|
Outer Dimensions (mm) : 725 × 525 × 1170 Outer Dimensions (mm) |
725 × 525 × 1170 |
|
Packing Size (mm) : 840 × 610 × 1310 Packing Size (mm) |
840 × 610 × 1310 |
|
Gross Weight : 150 kg Gross Weight |
150 kg |
|
Net Weight : 124 kg Net Weight |
124 kg |
