Tube Furnace 1400°C | 205 Mm Heating Zone FMT-08

Tube Furnace 1400°C | 205 Mm Heating Zone FMT-08

Name: Tube Furnace 1400°C | 205 Mm Heating Zone FMT-08
Brand: Labotemp
SKU: FMT-08
Price: 5095.00 USD
Availability: InStock
Rating: 4.8 (850 reviews)

Labotemp High-Temperature Tube Furnace FMT-08 is a precision laboratory tube furnace engineered for demanding thermal processes up to 1400°C (working ≤1300°C). It features a ∮80 mm corundum tube, 205 mm single heating zone, and 1000 mm total tube length. Powered by SiC heating rods with PID automatic control and 30-segment time–temperature programming, it delivers ±1°C accuracy and ±5°C uniformity. An S-type thermocouple and alumina ceramic fiber chamber ensure stable, high-efficiency operation in a compact 630×590×767 mm footprint.

Manufactured by a professional furnace manufacturer and supplied through authorised furnace suppliers, FMT-08 is ideal for high-temperature material synthesis, sintering, annealing, crystal growth, powder metallurgy, ceramic processing, semiconductor diffusion and heat treatment. The horizontal tubular design supports controlled-atmosphere and vacuum tube furnace configurations with optional touchscreen and PC software.

Why choose Labotemp Tube Furnace FMT-08?
✓ Ultra-High Temperature Performance: Ultra-high temperature performance up to 1400°C
✓ Precision & Repeatability: Precision PID control with repeatable thermal profiles
✓ Industrial-Grade Construction: Industrial-grade corundum tube and SiC heating system.

$5095

Datasheet

Maximum Temperature : 1400°C Maximum Temperature	1400°C
Standard Heating Zone Length (mm) : 205 Standard Heating Zone Length (mm)	205
Chamber Size (mm) : 80*205 Chamber Size (mm)	80*205
Standard Tube Diameter (mm) : ∮80 Standard Tube Diameter (mm)	∮80
Total Length of Furnace Tube (mm) : 1000 Total Length of Furnace Tube (mm)	1000
External Size : 630×590×767 mm External Size	630×590×767 mm
Working Temperature : ≤1300 Working Temperature	≤1300
Temperature Accuracy : ±1 Temperature Accuracy	±1
Temperature Uniformity : ±5 Temperature Uniformity	±5
Furnace Tube Material : Corundum Tube Furnace Tube Material	Corundum Tube
Heating Element : SiC Heating Rod Heating Element	SiC Heating Rod
Thermocouple Type : S Type Thermocouple Type	S Type
Chamber Material : Alumina Ceramic Fiber Chamber Material	Alumina Ceramic Fiber
Power Supply : AC 220V, 50Hz/60Hz Power Supply	AC 220V, 50Hz/60Hz
Net Weight : 100kg Net Weight	100kg
Gross Weight : 135kg Gross Weight	135kg

SiC Heating Rod  ➤ SiC Heating Rod
1400°C maximum operating temperature ➤ 1400°C maximum operating temperature
PID automatic control via current limiting phase angle fired the resistor ➤ PID automatic control via current limiting phase angle fired the resistor
30 segments “time–temperature curve” can be set arbitrarily ➤ 30 segments “time–temperature curve” can be set arbitrarily
The tube furnace uses high-purity quartz or alumina tubes as furnace tubes ➤ The tube furnace uses high-purity quartz or alumina tubes as furnace tubes
The furnace tubes are designed to be installed horizontally ➤ The furnace tubes are designed to be installed horizontally
The temperature zone is designed to be single zone ➤ The temperature zone is designed to be single zone

Used for high-temperature material synthesis, sintering, annealing, crystal growth, powder metallurgy, ceramic processing, semiconductor diffusion, coating development, and heat treatment experiments in laboratories ➤ Used for high-temperature material synthesis, sintering, annealing, crystal growth, powder metallurgy, ceramic processing, semiconductor diffusion, coating development, and heat treatment experiments in laboratories

Touch screen (with USB interface) ➤ Touch screen (with USB interface)
Computer connection software, control equipment (RKC, 16-segment program + interface + software) ➤ Computer connection software, control equipment (RKC, 16-segment program + interface + software)
Safety interlock (power-off function when door is opened) ➤ Safety interlock (power-off function when door is opened)
