Labotemp Vacuum Furnace FVA-14 is a large-capacity, ultra-high-temperature laboratory vacuum/atmosphere furnace for advanced thermal processing and materials research. It has a 20 L chamber (250 × 320 × 250 mm) and reaches 1700°C (1600°C working range). The FVA-14 supports vacuum heat treatment, vacuum annealing, high-temperature sintering, and controlled-atmosphere processing for ceramics, alloys, composites, and powder metallurgy.
MoSi₂ rod heating elements provide rapid thermal response, energy efficiency, uniform temperature distribution, and long service life under extreme cycling. Pre-vacuum capability enables low-oxygen and inert-gas processing to minimize oxidation. Water-cooling protects components for safe operation at ultra-high temperatures and extends equipment lifespan. Labotemp designs dependable, high-efficiency vacuum furnaces trusted by aerospace, semiconductor, energy, and materials research labs.
Why Choose Labotemp Vacuum Furnace FVA-14?
✓ Ultra-High Temperature Capability: Reliable operation up to 1700°C.
✓ Large Chamber Capacity: Ideal for bigger samples and pilot production.
✓ Efficient Heating: MoSi₂ elements for fast response and thermal stability.
✓ Industrial-Grade Safety: Water cooling for stable, long-term operation.
|
Model No. : FVA-14 Model No. |
FVA-14 |
|
Volume : 20L Volume |
20L |
|
Max Temp : 1700°C Max Temp |
1700°C |
|
Working Temp : 1600°C Working Temp |
1600°C |
|
Voltage : 380V / 50Hz Voltage |
380V / 50Hz |
|
Power : 7kW Power |
7kW |
|
Chamber Size : 250×320×250mm Chamber Size |
250×320×250mm |
|
Heating Element : MoSi₂ Rod Heating Element |
MoSi₂ Rod |
|
Vacuum / Pump System : No (Pre-vac Only) Vacuum / Pump System |
No (Pre-vac Only) |
|
Cooling Requirement : Yes (at 1700°C) Cooling Requirement |
Yes (at 1700°C) |
