Labotemp Platelet Incubator with Agitator LPA-104 is a high-capacity platelet preservation system designed to provide controlled temperature storage and continuous agitation for platelet concentrates in blood banks, hospitals, transfusion centers, and clinical laboratories. Engineered to maintain platelet viability during storage, the system combines precise temperature regulation with gentle horizontal oscillation to help prevent platelet aggregation and support optimal preservation conditions. Operating within a controlled temperature range of 15°C to 35°C, the unit utilizes microcomputer PID control, forced-air circulation, and automatic temperature monitoring to ensure stable and uniform storage conditions throughout the chamber.
Designed for large-scale platelet management, the LPA-104 features a spacious storage area with a double-door configuration, accommodating approximately 80–120 platelet bags across up to 40 shelves. The integrated Platelet Agitator system provides a 50 mm oscillation amplitude with adjustable speeds up to 60 cycles per minute, ensuring continuous and consistent platelet movement during storage. A stainless-steel interior, automatic defrost function, UV sterilization system, and high/low temperature alarms enhance operational reliability, hygiene, and sample protection.
Why Choose Labotemp Platelet Incubator with Agitator LPA-104?
✓ Large Storage Capacity: Accommodates approximately 80–120 platelet bags for high-volume blood bank operations.
✓ Continuous Platelet Agitation: Horizontal oscillation up to 60 cycles/min helps maintain platelet quality and viability.
✓ Stable Temperature Control: Microcomputer PID system with forced-air circulation ensures uniform chamber conditions.
| General Specifications | |
|
Power Supply : 220 V, 50/60 Hz Power Supply |
220 V, 50/60 Hz |
|
Storage Capacity : 80–120 Bags Storage Capacity |
80–120 Bags |
|
Temperature Control Range : 15°C–35°C Temperature Control Range |
15°C–35°C |
|
Temperature Accuracy : ±1°C Temperature Accuracy |
±1°C |
|
Temperature Fluctuation : ±1°C Temperature Fluctuation |
±1°C |
|
Temperature Control Mode : Microcomputer PID Control Temperature Control Mode |
Microcomputer PID Control |
|
Heating Power : 300 W Heating Power |
300 W |
|
Cooling Power : 130 W Cooling Power |
130 W |
|
Oscillation Type : Horizontal Oscillation Type |
Horizontal |
|
Speed Range : 0–60 cycles/min Speed Range |
0–60 cycles/min |
|
Oscillation Amplitude : 50 mm Oscillation Amplitude |
50 mm |
|
Air Circulation : Forced-Air Circulation Air Circulation |
Forced-Air Circulation |
|
Display : Digital Microcomputer Temperature Display Display |
Digital Microcomputer Temperature Display |
|
UV Sterilization : Built-in UV Sterilization Function UV Sterilization |
Built-in UV Sterilization Function |
|
Defrosting : Automatic Defrosting Defrosting |
Automatic Defrosting |
|
Chamber Motion : Left-Right Horizontal Reciprocating Motion Chamber Motion |
Left-Right Horizontal Reciprocating Motion |
|
Temperature Uniformity : Forced-Air Uniform Temperature Distribution Temperature Uniformity |
Forced-Air Uniform Temperature Distribution |
|
Alarm Functions : High/Low Temperature Alarm, Power Failure Alarm Alarm Functions |
High/Low Temperature Alarm, Power Failure Alarm |
| Storage & Construction | |
|
Number of Shelves : 20 Shelves × 2 (Double Door Type, Total 40 Shelves) Number of Shelves |
20 Shelves × 2 (Double Door Type, Total 40 Shelves) |
|
Viewing Window : Large Glass Viewing Window Viewing Window |
Large Glass Viewing Window |
|
Interior Material : Stainless Steel Interior Material |
Stainless Steel |
|
Insulation : High-Density Polyurethane Foam Insulation |
High-Density Polyurethane Foam |
|
Compressor Type : Fully Enclosed Low-Noise Compressor Compressor Type |
Fully Enclosed Low-Noise Compressor |
| Product Dimensions & Shipping | |
|
Net Weight : 320 kg Net Weight |
320 kg |
|
Gross Weight : 350 kg Gross Weight |
350 kg |
|
Package Size(W × D × H) : 1370 × 720 × 1970 mm Package Size(W × D × H) |
1370 × 720 × 1970 mm |
|
Internal Storage Area (W × D × H) : 980 × 300 × 810 mm Internal Storage Area (W × D × H) |
980 × 300 × 810 mm |
Volume: 15 L
Temperature Fluctuation: ±1°C
Temperature Control Range: 15 to 35°C
Temperature Control Mode: Microcomputer PID Control
Temperature Fluctuation: ±1°C
Temperature Control Range: 15 to 35°C
Temperature Control Mode: Microcomputer PID Control
Temperature Control Accuracy: ±1°C
Workbench Size: 350 × 350 × 8 Layers (48 Bags)
Timing Range: 0–9999 points or continuous operation
Speed Range: 50–70 RPM
Product Dimensions :
Viewing Window: Large Glass Viewing Window
UV Sterilization: Built-in UV Sterilization Function
Temperature Uniformity: Forced-Air Uniform Temperature Distribution
Temperature Fluctuation: ±1°C
Working Mode: Continuous left-right horizontal reciprocating agitation
Temperature Range: 22 ±2°C
Temperature Control Method: Digital Signal Detection, Microprocessor Control
Temperature Accuracy: ±0.1°C
UV Light: Yes
Thermal Printer: Yes
Temperature Sensor: NTC
Temperature Range: 20–24°C
UV Light: Built-in UV Light
Thermal Printer: Built-in thermal printer for temperature recording and documentation
Temperature Range: 20–24°C
Temperature Controller: Microprocessor
Working Mode: Continuous horizontal left-right reciprocating oscillation
Temperature Control Range: 22 ± 2°C
Temperature Control Method: Digital signal detection, microprocessor control
Temperature Control Accuracy: ±0.1°C
