Zirconia Sintering Furnace FDZ-07

Name: Zirconia Sintering Furnace FDZ-07
Brand: Labotemp
SKU: FDZ-07
Price: 6828.00 USD
Availability: InStock
Rating: 4.9 (746 reviews)

Labotemp Zirconia Sintering Furnace FDZ-07 is a high-temperature zirconia sintering furnace designed for controlled and repeatable sintering of zirconia dental materials. With a maximum temperature of 1630°C and a Φ60 mm × 130 mm firing chamber, it provides the temperature range and chamber space required for demanding dental laboratory workflows. The furnace features a touch-screen interface with real-time display of temperature, voltage, current, power, and the program running curve, allowing operators to monitor the sintering process clearly.

For flexible and repeatable operation, FDZ-07 provides 10 programmable sintering programs, with each program supporting 6 stages for setting heating rate, sintering temperature, and holding time. Heating rates can be programmed according to different temperature ranges, while sintering temperature can be set up to 1630°C with a holding time of up to 360 minutes. Timed sintering enables a preset start time, and the furnace can automatically open the tray as the temperature cools after a completed program. Mobile APP connectivity, power-outage operation recording, real-time running curves, and multiple alarm functions further support convenient monitoring and reliable operation.

Why Choose Labotemp Zirconia Furnace FDZ-07?

✓ Programmable Control: 10 programs with 6 programmable stages for customized sintering cycles.
✓ Real-Time Monitoring: Displays temperature, voltage, current, power, and program running curves.
✓ Smart Connectivity: Supports mobile APP operation and network-based furnace management.

$6828

Datasheet

General Specifications
Maximum Temperature : 1630 °C Maximum Temperature	1630 °C
Maximum Capacity : 70 units Maximum Capacity	70 units
Firing Chamber Size : Φ60 mm × 130 mm Firing Chamber Size	Φ60 mm × 130 mm
Number of Sintering Programs : 10 Number of Sintering Programs	10
Stages per Program : 6 Stages per Program	6
Sintering Temperature Setting Range : 0–1630 °C Sintering Temperature Setting Range	0–1630 °C
Sintering Temperature Hold Time : 0–360 minutes Sintering Temperature Hold Time	0–360 minutes
Heating & Sintering Parameters
Heat Rate, 0–1000 °C : 0–20 °C/min Heat Rate, 0–1000 °C	0–20 °C/min
Heat Rate, 1000–1300 °C : 0–15 °C/min Heat Rate, 1000–1300 °C	0–15 °C/min
Heat Rate, 1300–1630 °C : 0–10 °C/min Heat Rate, 1300–1630 °C	0–10 °C/min
Calibration Temperature : -50–50 °C Calibration Temperature	-50–50 °C
Scheduled Sintering : Available Scheduled Sintering	Available
Tray Opening Temperature Range : 600–1200 °C Tray Opening Temperature Range	600–1200 °C
Complete Tray Opening Temperature Range : 300–800 °C Complete Tray Opening Temperature Range	300–800 °C
Electrical & Control Specifications
Power Supply : 220 V ±10%, 50 Hz Power Supply	220 V ±10%, 50 Hz
Maximum Power Consumption : 2500 W Maximum Power Consumption	2500 W
Display & Control : Touch Screen Display & Control	Touch Screen
Mobile Connectivity : Mobile APP Operating System Mobile Connectivity	Mobile APP Operating System
Temperature Monitoring : Real-time Temperature Monitoring	Real-time
Parameter Monitoring : Temperature, Voltage, Current, Power Parameter Monitoring	Temperature, Voltage, Current, Power
Program Running Curve : Real-time Display Program Running Curve	Real-time Display
Power Outage Recording : Available Power Outage Recording	Available
Alarm Information : 12 Types Alarm Information	12 Types
Temperature Calibration : Available Temperature Calibration	Available
Screen Brightness Adjustment : 1–63 Screen Brightness Adjustment	1–63
Physical Dimensions
Furnace Unit Dimensions (W × H × D) : 585 mm × 380 mm × 830 mm Furnace Unit Dimensions (W × H × D)	585 mm × 380 mm × 830 mm
Furnace Unit Weight : 52 kg Furnace Unit Weight	52 kg

Sintering temperature1630°C ➤ Sintering temperature1630°C
Touchscreen control interface ➤ Touchscreen control interface
Mobile APP operating system ➤ Mobile APP operating system
10 programmable sintering programs ➤ 10 programmable sintering programs
6 programmable stages per sintering program ➤ 6 programmable stages per sintering program
Adjustable heating rates for different temperature ranges ➤ Adjustable heating rates for different temperature ranges
Real-time temperature monitoring ➤ Real-time temperature monitoring
Real-time display of voltage, current and power ➤ Real-time display of voltage, current and power
Real-time program running curve ➤ Real-time program running curve
High-quality heating element designed for long service life ➤ High-quality heating element designed for long service life
Power-outage running-state recording ➤ Power-outage running-state recording
Scheduled/timed sintering function ➤ Scheduled/timed sintering function
Programmable sintering temperature and holding time ➤ Programmable sintering temperature and holding time
Automatic tray opening during the cooling process ➤ Automatic tray opening during the cooling process
Temperature calibration function ➤ Temperature calibration function
Multiple alarm functions for operating-status monitoring ➤ Multiple alarm functions for operating-status monitoring
Network configuration and connected furnace management ➤ Network configuration and connected furnace management
QR code identification for furnace connectivity ➤ QR code identification for furnace connectivity

Zirconia Sintering: Used for controlled high-temperature sintering of zirconia dental materials Zirconia Sintering
Used for controlled high-temperature sintering of zirconia dental materials
Dental Crown & Bridge Production: Supports thermal processing workflows for zirconia-based dental restorations Dental Crown & Bridge Production
Supports thermal processing workflows for zirconia-based dental restorations
Dental Laboratory Processing: Suitable for dental laboratories requiring programmable and repeatable zirconia sintering cycles Dental Laboratory Processing
Suitable for dental laboratories requiring programmable and repeatable zirconia sintering cycles
Customized Sintering Cycles: Six-stage programmable profiles allow sintering parameters to be adjusted for different material and processing requirements Customized Sintering Cycles
Six-stage programmable profiles allow sintering parameters to be adjusted for different material and processing requirements
