Cryostat Microtome CRM-02

Name: Cryostat Microtome CRM-02
Brand: Labotemp
SKU: CRM-02
Price: 17015.00 USD
Availability: InStock
Rating: 4.7 (681 reviews)

Labotemp Cryostat Microtome CRM-02 is a high-performance microtome machine designed for precise cryostat sectioning and microtomy in histopathology. Also referred to as a freezing microtome or cryotome, this cryostat microtome enables reliable frozen tissue sectioning for intraoperative diagnosis and urgent pathology workflows. The RD-2280 delivers consistent thin sections with an adjustable cut thickness from 0.5 µm to 100 µm, supporting accurate microtomy and dependable sample preparation.

The fully enclosed cryogenic chamber operates from 0°C to –60°C, ensuring stable freezing conditions for reproducible results. Precise specimen control with 65 mm vertical stroke, 22 mm horizontal stroke, and up to 100 µm specimen retraction improves section quality and protects the blade. A rigid microtome blade holder supports standard disposable blades and knives, maintaining a stable cutting edge for clean, repeatable sections.

Why choose Labotemp Cryostat Microtome CRM-02?
✓Wide sectioning range: Accurate frozen sections from 0.5–100 µm
✓Stable freezing control: Reliable operation down to –60°C
✓Laboratory safety: Enclosed chamber with UV disinfection

$17015

Datasheet

General Specifications
Section Thickness Range : 0.5–100 µm adjustable Section Thickness Range	0.5–100 µm adjustable
Section Thickness Setting : 0.5–2 µm in 0.5 µm increment<br> 5–20 µm in 1 µm increment<br>20–40 µm in 2 µm increment<br>40–100 µm in 5 µm increment Section Thickness Setting	0.5–2 µm in 0.5 µm increment 5–20 µm in 1 µm increment 20–40 µm in 2 µm increment 40–100 µm in 5 µm increment
Trimming Thickness Range : 10–600 µm adjustable<br>10–50 µm in 5 µm increment<br>50–100 µm in 10 µm increment<br>100–600 µm in 50 µm increment Trimming Thickness Range	10–600 µm adjustable 10–50 µm in 5 µm increment 50–100 µm in 10 µm increment 100–600 µm in 50 µm increment
Tissue Retraction Function : 0–100 µm adjustable in 5 µm increment Tissue Retraction Function	0–100 µm adjustable in 5 µm increment
Pellet Cooling Working Time : 15 minutes Pellet Cooling Working Time	15 minutes
Freezing Chamber Temperature Range : 10°C to −50°C Freezing Chamber Temperature Range	10°C to −50°C
Speed of Fast Forward / Backward : 0.9 m/s, 0.45 m/s Speed of Fast Forward / Backward	0.9 m/s, 0.45 m/s
Specimen Head Minimum Temperature : 10°C to −50°C Specimen Head Minimum Temperature	10°C to −50°C
Maximum Specimen Size : 55 × 60 mm Maximum Specimen Size	55 × 60 mm
Freeze Shelf Minimum Temperature : −50°C Freeze Shelf Minimum Temperature	−50°C
Lowest Temperature of Peltier Units on Freezing Shelf : −60°C Lowest Temperature of Peltier Units on Freezing Shelf	−60°C
Specimen Vertical Stroke : 65 mm Specimen Vertical Stroke	65 mm
Specimen Horizontal Stroke : 22 mm Specimen Horizontal Stroke	22 mm
Voltage and Frequency : AC 220 V / 50 Hz Voltage and Frequency	AC 220 V / 50 Hz
Quantity of Peltier Units : 8 pcs Quantity of Peltier Units	8 pcs
Disinfection Method : UV Disinfection Method	UV
Construction & Operations
Chamber Design : Fully enclosed cryogenic chamber Chamber Design	Fully enclosed cryogenic chamber
Specimen Retraction : Adjustable up to 100 µm Specimen Retraction	Adjustable up to 100 µm
Specimen Movement : Controlled vertical and horizontal movement Specimen Movement	Controlled vertical and horizontal movement
Handwheel : 16-position handwheel Handwheel	16-position handwheel
Compressor : Danfoss brand compressor Compressor	Danfoss brand compressor
Blade Compatibility : Standard disposable microtome blades and knives Blade Compatibility	Standard disposable microtome blades and knives
Control : Touchscreen control Control	Touchscreen control
Product Dimensions
Dimensions (W × D × H) : 700 × 780 × 1160 mm Dimensions (W × D × H)	700 × 780 × 1160 mm
Package Size(W × D × H) : 930 × 870 × 1450 mm Package Size(W × D × H)	930 × 870 × 1450 mm
Net Weight : 210Kg Net Weight	210Kg
Gross Weight : 225Kg Gross Weight	225Kg

Touchscreen Control ➤ Touchscreen Control
Provides convenient operation and adjustment of sectioning parameters. ➤ Provides convenient operation and adjustment of sectioning parameters.
0.5–100 µm adjustment supports diverse frozen tissue sectioning requirements. ➤ 0.5–100 µm adjustment supports diverse frozen tissue sectioning requirements.
Provides space for preparing multiple specimens during laboratory workflows. ➤ Provides space for preparing multiple specimens during laboratory workflows.
Up to 100 µm retraction helps protect the blade and improve section quality. ➤ Up to 100 µm retraction helps protect the blade and improve section quality.
Improves visibility inside the working area. ➤ Improves visibility inside the working area.
Supports hygienic operation and chamber disinfection. ➤ Supports hygienic operation and chamber disinfection.
Helps maintain stable cryogenic conditions during sectioning. ➤ Helps maintain stable cryogenic conditions during sectioning.
Supports controlled and safer specimen movement. ➤ Supports controlled and safer specimen movement.
Eight Peltier units provide controlled low-temperature freezing performance. ➤ Eight Peltier units provide controlled low-temperature freezing performance.
Supports dependable cooling operation for routine cryostat workflows. ➤ Supports dependable cooling operation for routine cryostat workflows.
65 mm vertical and 22 mm horizontal strokes enable accurate positioning. ➤ 65 mm vertical and 22 mm horizontal strokes enable accurate positioning.
0.9 m/s and 0.45 m/s speeds support efficient specimen positioning. ➤ 0.9 m/s and 0.45 m/s speeds support efficient specimen positioning.
Rigid blade-holder design supports disposable blades and microtome knives. ➤ Rigid blade-holder design supports disposable blades and microtome knives.

Intraoperative Diagnosis: Enables rapid preparation of frozen tissue sections for time-sensitive surgical and pathological evaluation Intraoperative Diagnosis
Enables rapid preparation of frozen tissue sections for time-sensitive surgical and pathological evaluation
Histopathology Laboratories: Supports frozen tissue sectioning for routine and specialized histological examination Histopathology Laboratories
Supports frozen tissue sectioning for routine and specialized histological examination
Pathology Laboratories: Suitable for urgent pathology workflows requiring rapid tissue preparation and microscopic analysis Pathology Laboratories
Suitable for urgent pathology workflows requiring rapid tissue preparation and microscopic analysis
Surgical Departments: Supports frozen-section preparation during surgical procedures where rapid tissue assessment is required Surgical Departments
Supports frozen-section preparation during surgical procedures where rapid tissue assessment is required
Oncology Units: Useful for rapid evaluation of fresh tumor tissue and intraoperative pathological assessment Oncology Units
Useful for rapid evaluation of fresh tumor tissue and intraoperative pathological assessment
Research Laboratories: Supports cryogenic preparation of fresh and frozen biological tissue specimens for research and microscopy Research Laboratories
Supports cryogenic preparation of fresh and frozen biological tissue specimens for research and microscopy
