Labotemp Pulse Vacuum Sterilizer LPS-105 is a high-capacity pulse vacuum autoclave engineered for reliable steam sterilization in hospitals, pharmaceutical manufacturing, biotechnology facilities, research laboratories, and central sterile supply departments (CSSD). Featuring a 360 L rectangular stainless steel chamber, sterilization temperatures up to 139°C, and a maximum vacuum level of −96 kPa, this autoclave sterilizer ensures deep steam penetration into surgical instruments, textiles, glassware, rubber products, lumen devices, and wrapped porous loads. Advanced pulse vacuum technology removes over 99.99% of chamber air before sterilization, improving steam distribution and delivering consistent, repeatable sterilization results. The Siemens PLC control system with color touch screen provides precise monitoring of temperature, pressure, time, and sterilization cycles for dependable operation.
Designed for continuous institutional use, this autoclave machine integrates flash vacuum drying technology to minimize residual moisture and improve workflow efficiency. The automatic vertical sliding door with inflatable silicone sealing system enhances safety and airtight performance, while built-in protection features including over-pressure alarms, vacuum leakage detection, automatic drainage temperature control, and supply system monitoring ensure secure operation. Stainless steel sanitary pipelines, programmable sterilization programs, optional remote monitoring, and low steam consumption make the LPS-105 a durable, energy-efficient solution for demanding laboratory and medical sterilization applications.
Why Choose Labotemp Pulse Vacuum Sterilizer LPS-105?
✓ Advanced Pulse Vacuum Technology: Removes over 99.99% of chamber air for superior steam penetration.
✓ Intelligent PLC Automation: Siemens touch-screen control with programmable sterilization cycles and real-time monitoring.
✓ Efficient Flash Vacuum Drying: Delivers low residual moisture for faster post-sterilization handling.
| General Specifications | |
|
Chamber Capacity : 360 L Chamber Capacity |
360 L |
|
Maximum Operating Temperature : 139°C Maximum Operating Temperature |
139°C |
| Sterilization Parameters | |
|
Sterilization Temperature : 116°C to 139°C Sterilization Temperature |
116°C to 139°C |
|
Maximum Vacuum Level : -96 kPa Maximum Vacuum Level |
-96 kPa |
|
Vacuum Leakage Rate : ≤ 0.13 kPa/min Vacuum Leakage Rate |
≤ 0.13 kPa/min |
|
Maximum Operating Pressure : 0.25 MPa Maximum Operating Pressure |
0.25 MPa |
|
Temperature Control Accuracy : ±1°C Temperature Control Accuracy |
±1°C |
|
Temperature Uniformity : ±1°C Temperature Uniformity |
±1°C |
|
Temperature Display Resolution : 0.1°C Temperature Display Resolution |
0.1°C |
|
Pressure Display Resolution : 0.1 kPa Pressure Display Resolution |
0.1 kPa |
|
Positive Pressure Pulse : 0–9 times Positive Pressure Pulse |
0–9 times |
|
Negative Pressure Pulse : -80 to 0 kPa Negative Pressure Pulse |
-80 to 0 kPa |
|
Cross Pressure Pulsation : -80 to 80 kPa Cross Pressure Pulsation |
-80 to 80 kPa |
| Operation | |
|
Steam Consumption : 20 kg/Cycle Steam Consumption |
20 kg/Cycle |
|
Water Consumption : 160 kg/Cycle Water Consumption |
160 kg/Cycle |
|
Power Supply : 380 V, 50 Hz Power Supply |
380 V, 50 Hz |
|
Power Rating : 2 kW + 20 kW Power Rating |
2 kW + 20 kW |
|
Chamber Design Pressure : -0.1 / 0.3 MPa Chamber Design Pressure |
-0.1 / 0.3 MPa |
|
Jacket Design Pressure : 0.3 MPa Jacket Design Pressure |
0.3 MPa |
|
Steam Generator Design Pressure : 1.0 MPa Steam Generator Design Pressure |
1.0 MPa |
|
Chamber Relief Valve : 0.28 MPa Chamber Relief Valve |
0.28 MPa |
|
Jacket Relief Valve : 0.28 MPa Jacket Relief Valve |
0.28 MPa |
| Physical Dimensions | |
|
Chamber Dimensions (W × H × D) : 610 × 610 × 1000 mm Chamber Dimensions (W × H × D) |
610 × 610 × 1000 mm |
|
Overall Dimensions (L × W × H) : 1355 × 1160 × 1950 mm Overall Dimensions (L × W × H) |
1355 × 1160 × 1950 mm |
|
Package Size : 1305 × 1500 × 2290 mm Package Size |
1305 × 1500 × 2290 mm |
|
Package Size (transfer vehicles) : 1000 × 1330 × 880 mm Package Size (transfer vehicles) |
1000 × 1330 × 880 mm |
|
Net Weight : 870 kg Net Weight |
870 kg |
|
Gross Weight : 1070 kg Gross Weight |
1070 kg |
