Labotemp Hydrothermal Reactor Autoclave HRA-04 is a 200mL, PTFE-lined hydrothermal autoclave engineered for hydrothermal synthesis, pressure digestion and catalytic hydrothermal reactions. The 304 stainless-steel kettle (10 mm wall) with secure gasketed lid and PTFE lining resists strong acids/alkalis and enables rapid, nondestructive dissolution of insoluble or volatile samples. Rated for 200°C operating (250°C max) and 3.0 MPa, it replaces platinum crucibles for trace-element prep and supports autoclave for hydrothermal synthesis workflows.
Compact and robust, HRA-04 suits petrochemical, biomedical, materials, geological, environmental and food labs for heavy-metal, pesticide, rare-earth and organic sample pretreatment. The 200mL capacity, 63mm inner diameter and 5.65 kg portable design deliver reproducible digestion, reduced contamination and safe, easy operation. Labotemp, a trusted autoclave manufacturer and leading hydrothermal autoclave suppliers, delivering precision-engineered.
Why choose Labotemp Hydrothermal Reactor HRA-04?
✓ Manufactured by experts: Built by experienced autoclave manufacturers with 304 stainless steel body and PTFE lining.
✓ Compliance & safety: ISO 13485 & CE certified, rated to 250°C and 3.0 MPa for secure hydrothermal digestion.
✓ Lab efficiency: 200mL capacity, thick-walled kettle and low-contamination design for fast, reliable sample preparation.
| General Specifications | |
|
Capacity : 200 ml Capacity |
200 ml |
|
Kettle Body Material : Stainless Steel Kettle Body Material |
Stainless Steel |
| Sterilization Parameters | |
|
Maximum Temperature : 250°C Maximum Temperature |
250°C |
|
Maximum Pressure : 3.0 MPa Maximum Pressure |
3.0 MPa |
| Chamber Dimensions | |
|
Kettle Lid Height : 50 mm Kettle Lid Height |
50 mm |
|
Kettle Body Height : 155 mm Kettle Body Height |
155 mm |
|
Kettle Body Diameter : 83 mm Kettle Body Diameter |
83 mm |
|
Kettle Body Inner Diameter : 63 mm Kettle Body Inner Diameter |
63 mm |
|
Kettle Body Wall Thickness : 10 mm Kettle Body Wall Thickness |
10 mm |
|
Inner Diameter : 63 mm Inner Diameter |
63 mm |
| Physical Dimensions | |
|
Overall Height : 210 mm Overall Height |
210 mm |
|
Length of Grip Bar : 8 × 120 mm Length of Grip Bar |
8 × 120 mm |
|
Lined With High : 134 mm Lined With High |
134 mm |
|
Lining Height / Thickness : 8 mm Lining Height / Thickness |
8 mm |
|
Thickness of Lower Gasket : 10 mm Thickness of Lower Gasket |
10 mm |
|
Thickness of Upper Gasket : 10 mm Thickness of Upper Gasket |
10 mm |
| Packaging Information | |
|
Product Weight : 5.65 kg Product Weight |
5.65 kg |
|
Packing Dimension : 16.5 × 16.5 × 27.5 cm Packing Dimension |
16.5 × 16.5 × 27.5 cm |
|
Gross Weight : 8 kg Gross Weight |
8 kg |
Thickness of Upper Gasket: 8 mm
Thickness of Lower Gasket: 8 mm
Sterilization Parameters:
Product Weight: 0.95 kg
Thickness of Upper Gasket: 8 mm
Thickness of Lower Gasket: 8 mm
Sterilization Parameters:
Product Weight: 0.95 kg
Sterilization Parameters:
Product Weight: 2.25 kg
Packaging Information:
Operating Temperature: 200°C
Thickness of Upper Gasket: 10 mm
Thickness of Lower Gasket: 10 mm
Sterilization Parameters:
Product Weight: 5.65 kg
Thickness of Upper Gasket: 10 mm
Thickness of Lower Gasket: 10 mm
Sterilization Parameters:
Product Weight: 6.4 kg
Thickness of Upper Gasket: 10 mm
Thickness of Lower Gasket: 10 mm
Sterilization Parameters:
Product Weight: 6.5 kg
Thickness of Upper Gasket: 10 mm
Thickness of Lower Gasket: 10 mm
Sterilization Parameters:
Product Weight: 7.45 kg
Wetted Material: Hastelloy
Venting System: Deflation / Vent Valve
Valve Material: 316L Stainless Steel
Temperature Monitoring: Temperature Probe
Wetted Material: Hastelloy
Venting System: Deflation / Vent Valve
Valve Material: 316L Stainless Steel
Temperature Monitoring: Temperature Probe
