Cryogenic Chamber CTC-02

Name: Cryogenic Chamber CTC-02
Brand: Labotemp
SKU: CTC-02
Price: 48279.00 USD
Availability: InStock
Rating: 4.9 (701 reviews)

Labotemp Cryogenic Chamber CTC-02 provides precise environmental control with a wide −120°C to +150°C temperature range for cryogenic testing, material research, and thermal simulation. It features a cascade refrigeration system, Nichrome heating, PT100Ω sensors, and a programmable LCD touchscreen for intelligent control. Built with a steel exterior, SUS304 stainless-steel interior, and polyurethane insulation, it ensures durability and stability. Strong airflow, low noise, and multiple safety protections make it ideal for advanced laboratory applications.

This cryo chamber is designed for demanding applications including aerospace material testing, electronic component validation, defense equipment reliability, and industrial temperature simulation.Ideal as a thermal chamber, stability chamber, and climatic test chamber, it supports precise research and quality testing. With compressor-based cooling, durable insulated construction, and CE and ISO 13485 compliance, it serves as a reliable cryo chamber and cryogenic freezing chamber from a trusted test chamber manufacturer.

Why Choose Labotemp Cryogenic Chamber CTC-02?
✓ Wide range: Ideal cryogenic chamber and environmental test chamber for extreme temperature testing
✓ Stable results: Reliable performance as temperature chamber and climatic test chamber
✓ Trusted quality: Durable cryo chamber from a certified cryogenic chamber manufacturer

$48279

Datasheet

Temperature Range : -120°C ~ +150°C Temperature Range	-120°C ~ +150°C
Interior Volume : 500L Interior Volume	500L
Power Supply : 380V 50Hz Power Supply	380V 50Hz
Internal Dimension (mm) : 700×800×900 Internal Dimension (mm)	700×800×900
Overall Dimension (mm) : 1200×1340×2020 Overall Dimension (mm)	1200×1340×2020
Temperature Fluctuation : ±0.5°C Temperature Fluctuation	±0.5°C
Temperature Deviation : ±2.0°C Temperature Deviation	±2.0°C
Cooling Rate : 1°C / min Cooling Rate	1°C / min
Heating Rate : 3°C / min Heating Rate	3°C / min
Cooling System : Mechanical compression refrigeration system Cooling System	Mechanical compression refrigeration system
Refrigerating Unit : Cascade compressor Refrigerating Unit	Cascade compressor
Heating Element : Nichrome heater Heating Element	Nichrome heater
Controller : Programmable color LCD touch screen controller, Ethernet connection, PC Link Controller	Programmable color LCD touch screen controller, Ethernet connection, PC Link
Temperature Sensor : PTR Platinum Resistance PT100Ω / MV A-class Temperature Sensor	PTR Platinum Resistance PT100Ω / MV A-class
Air Circulation : Centrifugal wind fan Air Circulation	Centrifugal wind fan
Exterior Material : Steel Plate with protective coating Exterior Material	Steel Plate with protective coating
Interior Material : SUS304 stainless steel Interior Material	SUS304 stainless steel
Thermal Insulation : Polyurethane foam and insulation cotton Thermal Insulation	Polyurethane foam and insulation cotton
Observation Window : Interior lighting, double-layer thermo stability silicone rubber sealing Observation Window	Interior lighting, double-layer thermo stability silicone rubber sealing
Standard Configuration : 1 Cable hole (Φ50) with plug; 2 shelves Standard Configuration	1 Cable hole (Φ50) with plug; 2 shelves
Maximum Noise : 65 dBA Maximum Noise	65 dBA
Safety Device : Over-temperature Protection; Over-current Protection; Refrigerant High-Pressure Protection; Earth leakage Protection Safety Device	Over-temperature Protection; Over-current Protection; Refrigerant High-Pressure Protection; Earth leakage Protection
Net Weight : 610kg Net Weight	610kg
Gross Weight : 756kg Gross Weight	756kg
Package Size : 2050x1470x2300mm Package Size	2050x1470x2300mm

No Liquid Nitrogen ➤ No Liquid Nitrogen
Mechanical compressor cooling to –120°C (no liquid nitrogen) ➤ Mechanical compressor cooling to –120°C (no liquid nitrogen)
Wide temperature range –120°C to +150°C ➤ Wide temperature range –120°C to +150°C
High-accuracy PT100 sensor (0.001°C) ➤ High-accuracy PT100 sensor (0.001°C)
7-inch PID touch controller with Ethernet & USB ➤ 7-inch PID touch controller with Ethernet & USB
French TECUMSEH compressor with eco-friendly refrigerant ➤ French TECUMSEH compressor with eco-friendly refrigerant
Uniform air circulation using centrifugal fan ➤ Uniform air circulation using centrifugal fan
SUS304 stainless steel interior with adjustable shelves ➤ SUS304 stainless steel interior with adjustable shelves
Double-layer glass window with anti-frost film & LED light ➤ Double-layer glass window with anti-frost film & LED light
Nichrome heater for fast and stable heating ➤ Nichrome heater for fast and stable heating
Multiple safety protections (over-temp, over-current, high-pressure, earth leakage) ➤ Multiple safety protections (over-temp, over-current, high-pressure, earth leakage)
10cm polyurethane insulation for high efficiency ➤ 10cm polyurethane insulation for high efficiency
A3 galvanized steel exterior for durability ➤ A3 galvanized steel exterior for durability
Movable castors with brakes for easy handling ➤ Movable castors with brakes for easy handling

Used in Aerospace material testing, military equipment reliability testing, electronic component performance testing, high-precision industry low-temperature testing, high-end processing and quenching processes, and extreme environment simulation for product stability ➤ Used in Aerospace material testing, military equipment reliability testing, electronic component performance testing, high-precision industry low-temperature testing, high-end processing and quenching processes, and extreme environment simulation for product stability
