Tissue Water Bath With Slide Dryer LTB-102

Tissue Water Bath With Slide Dryer LTB-102

Name: Tissue Water Bath With Slide Dryer LTB-102
Brand: Labotemp
SKU: LTB-102
Price: 5135.00 USD
Availability: InStock
Rating: 4.9 (701 reviews)

Labotemp Histology Tissue Water Bath with Slide Dryer LTB-102 streamlines tissue section preparation by integrating a tissue water bath, slide dryer, and baking oven into a single compact workstation. Designed for histopathology laboratories, hospitals, medical colleges, research institutes, and diagnostic centers, the system provides independent temperature control for each working zone, with an adjustable range of 0°C to 75°C. The 2.5 L tissue water bath gently flattens paraffin sections before mounting, while the integrated slide dryer accommodates up to 60 microscope slides for efficient drying and baking prior to staining. A precision temperature control system maintains ±1°C accuracy, ensuring consistent sample preparation and dependable laboratory performance.

Built for reliable daily operation, the LTB-102 features an intuitive LCD touch screen with programmable start/stop scheduling for up to one week, countdown reminders, and independent control of the water bath, slide dryer, and oven. Computer and hardware dual temperature protection help safeguard valuable tissue specimens, while the integrated LED illumination improves visibility when handling floating tissue sections. Adjustable screen and lighting brightness, multiple baking modes, and a durable benchtop design support efficient workflows in high-volume pathology laboratories. Combining accurate temperature control, user-friendly operation, and versatile functionality, the LTB-102 offers a practical solution for preparing high-quality tissue sections for microscopic examination.

Why Choose Labotemp Histology Tissue Water Bath with Slide Dryer LTB-102?

✓ 3-in-1 Workstation: Combines tissue water bath, slide dryer, and baking oven in one compact unit.
✓ Independent Temperature Control: Separate control for each heating zone with ±1°C accuracy.
✓ High Sample Capacity: Accommodates up to 60 microscope slides for efficient laboratory workflows.

$5135

Datasheet

Temperature & Performance
Water Bath Temperature Range : 0°C – 75°C (0°C – 99°C Optional) Water Bath Temperature Range	0°C – 75°C (0°C – 99°C Optional)
Slide Dryer Temperature Range : 0°C – 75°C (0°C – 99°C Optional) Slide Dryer Temperature Range	0°C – 75°C (0°C – 99°C Optional)
Oven Temperature Range : 0°C – 75°C (0°C – 99°C Optional) Oven Temperature Range	0°C – 75°C (0°C – 99°C Optional)
Temperature Accuracy : ±1°C Temperature Accuracy	±1°C
Timing Range : Programmable up to 1 Week Timing Range	Programmable up to 1 Week
Working Temperature : 0°C – 40°C Working Temperature	0°C – 40°C
Operating Humidity : ≤80% RH Operating Humidity	≤80% RH
Electrical & Compliance
Power Supply : AC 220V ±10%, 50Hz Power Supply	AC 220V ±10%, 50Hz
Power Consumption : 600 VA Power Consumption	600 VA
Fuse Rating : 10 A Fuse Rating	10 A
Design & Capacity
Slide Capacity : Up to 60 Slides Slide Capacity	Up to 60 Slides
Tissue water bath capacity : 2.5 L Tissue water bath capacity	2.5 L
Display : LCD Touch Screen Display	LCD Touch Screen
Control System : Independent Three-Zone Temperature Control Control System	Independent Three-Zone Temperature Control
Lighting : Bottom LED Illumination with Adjustable Brightness Lighting	Bottom LED Illumination with Adjustable Brightness
Overall Dimensions : 570 × 430 × 180 mm Overall Dimensions	570 × 430 × 180 mm
Water Bath Tank Size : 210 × 170 × 55 mm Water Bath Tank Size	210 × 170 × 55 mm
Net Weight : 14kg Net Weight	14kg
Gross Weight : 20kg Gross Weight	20kg
Package Size : 640 × 500 × 250 mm Package Size	640 × 500 × 250 mm

3-in-1 Workstation ➤ 3-in-1 Workstation
Independent temperature control for the water bath, dryer, and oven. ➤ Independent temperature control for the water bath, dryer, and oven.
2.5 L water bath for efficient tissue section floating and flattening. ➤ 2.5 L water bath for efficient tissue section floating and flattening.
Slide drying platform accommodates up to 60 microscope slides. ➤ Slide drying platform accommodates up to 60 microscope slides.
LCD touch screen for simple operation and parameter monitoring. ➤ LCD touch screen for simple operation and parameter monitoring.
Programmable timer with start/stop scheduling for up to one week. ➤ Programmable timer with start/stop scheduling for up to one week.
Dual over-temperature protection for safe and reliable operation. ➤ Dual over-temperature protection for safe and reliable operation.
Uniform heating ensures consistent drying and baking performance. ➤ Uniform heating ensures consistent drying and baking performance.
Integrated LED illumination improves visibility during tissue handling. ➤ Integrated LED illumination improves visibility during tissue handling.
Adjustable display and LED brightness for user convenience. ➤ Adjustable display and LED brightness for user convenience.

Histopathology Laboratories: Supports tissue section floating, drying, and baking for accurate histological sample preparation Histopathology Laboratories
Supports tissue section floating, drying, and baking for accurate histological sample preparation
Hospitals & Diagnostic Centres: Enables efficient preparation of pathology slides for routine clinical diagnosis and laboratory workflows Hospitals & Diagnostic Centres
Enables efficient preparation of pathology slides for routine clinical diagnosis and laboratory workflows
Medical Colleges & Universities: Suitable for practical training and teaching in histology, pathology, and biomedical laboratory courses Medical Colleges & Universities
Suitable for practical training and teaching in histology, pathology, and biomedical laboratory courses
Research Institutes: Provides controlled heating for tissue processing in biomedical, life science, and translational research Research Institutes
Provides controlled heating for tissue processing in biomedical, life science, and translational research
Pharmaceutical & Biotechnology: Assists in tissue sample preparation for preclinical studies, quality control, and research applications Pharmaceutical & Biotechnology
Assists in tissue sample preparation for preclinical studies, quality control, and research applications
Food Testing Laboratories: Useful for preparing biological specimens for microscopic examination during food safety and analytical testing Food Testing Laboratories
Useful for preparing biological specimens for microscopic examination during food safety and analytical testing
