Horizontal Autoclave HZA-03

Name: Horizontal Autoclave HZA-03
Brand: Labotemp
SKU: HZA-03
Price: 9669.00 USD
Availability: InStock
Rating: 4.7 (658 reviews)

Labotemp Horizontal Autoclave HZA-03 is a reliable horizontal autoclave machine designed to sterilize laboratory instruments, glassware, culture media, and medical dressing materials. This horizontal steam sterilizer uses saturated steam at controlled temperature and pressure to eliminate bacteria, viruses, and spores. It is widely used in pharmaceutical units, hospitals, research labs, and testing facilities. The horizontal cylindrical autoclave design ensures easy loading, safe operation, and consistent sterilization performance.

This horizontal cylindrical pressure steam sterilizer features a 400L stainless steel chamber, operating at 0.22 MPa and up to 134°C for effective sterilization. With adjustable temperature from 40°C to 134°C and sterilization and drying time from 0–60 minutes, it offers operational flexibility. Built with automatic control, drying function, and ISO & CE compliance, Labotemp is a trusted autoclave sterilizer manufacturer providing durable sterilization solutions.

Why Choose Labotemp Horizontal Autoclave HZA-03?
✓ ISO & CE Compliance: Manufactured as per ISO & CE standards for reliable and safe sterilization performance.
✓ Automatic Sterilization & Drying: Automatic sterilization cycle with drying function ensures efficient and convenient operation.
✓Trusted Autoclave Supplier: Labotemp is a trusted autoclave supplier, offering reliable and durable sterilization solutions.

$9669

Datasheet

General Specifications
Working Temperature : 134°C Working Temperature	134°C
Volume : 400 L Volume	400 L
Sterilizing Chamber : 700 × 1100 mm Sterilizing Chamber	700 × 1100 mm
Time of Sterilization : 0–60 min Time of Sterilization	0–60 min
Working Pressure : 0.22 MPa Working Pressure	0.22 MPa
Time of Drying : 0–60 min Time of Drying	0–60 min
Heat Average : ≤ ±2°C Heat Average	≤ ±2°C
Temperature Adjustment : 40°C–134°C Temperature Adjustment	40°C–134°C
Electrical & Construction
Power : 18 kW Power	18 kW
Voltage : 380 V, 50 Hz Voltage	380 V, 50 Hz
Packaging Information
Dimension : 1430 × 880 × 1830 mm Dimension	1430 × 880 × 1830 mm
Transport Dimension : 1600 × 1050 × 2100 mm Transport Dimension	1600 × 1050 × 2100 mm
Gross Weight : 530 kg Gross Weight	530 kg
Net Weight : 420 kg Net Weight	420 kg

400L Large Capacity ➤ 400L Large Capacity
Sterilizing course automatic sterilization control, easy to operate ➤ Sterilizing course automatic sterilization control, easy to operate
With drying function, suitable for dressing drying ➤ With drying function, suitable for dressing drying
Over-temperature and over-pressure auto-protect device ➤ Over-temperature and over-pressure auto-protect device
Door cannot open until chamber pressure drops to 0 ➤ Door cannot open until chamber pressure drops to 0
027MPa; machine cannot start if door is not closed properly ➤ 027MPa; machine cannot start if door is not closed properly
Safety valve opens automatically when inner pressure exceeds 0 ➤ Safety valve opens automatically when inner pressure exceeds 0
24MPa, releasing steam into water tank ➤ 24MPa, releasing steam into water tank
Automatic power cut-off, water cut-off, and alarm when water is lacking ➤ Automatic power cut-off, water cut-off, and alarm when water is lacking
Stainless steel chamber ➤ Stainless steel chamber

Research & Microbiology Laboratories: Suitable for sterilizing laboratory glassware, instruments, culture media, solutions, and biological waste Research & Microbiology Laboratories
Suitable for sterilizing laboratory glassware, instruments, culture media, solutions, and biological waste
Healthcare & Medical Facilities: Supports sterilization of compatible dressing materials, instruments, and reusable laboratory equipment Healthcare & Medical Facilities
Supports sterilization of compatible dressing materials, instruments, and reusable laboratory equipment
Laboratory Glassware Sterilization: Ideal for high-volume processing of laboratory bottles, containers, glassware, and other heat- and moisture-compatible items Laboratory Glassware Sterilization
Ideal for high-volume processing of laboratory bottles, containers, glassware, and other heat- and moisture-compatible items
Culture Media & Solutions: Suitable for steam sterilization of prepared culture media and compatible laboratory solutions Culture Media & Solutions
Suitable for steam sterilization of prepared culture media and compatible laboratory solutions
Industrial Applications: Designed for sterilization of larger quantities of compatible components and materials where high-capacity steam processing is required Industrial Applications
Designed for sterilization of larger quantities of compatible components and materials where high-capacity steam processing is required
