Labotemp Sand Dust Test Chamber SDC-05 provides a large-capacity environment for controlled dust exposure testing of electronics, automotive components, military equipment, and industrial products. With an 8000 L interior volume, 2000 × 2000 × 2000 mm working space, ambient to +50°C temperature range, and humidity below 30% RH, it supports large specimens and demanding test programs. Designed for IP5X and IP6X testing based on IEC 60529 and ISO 20653 test methods, the chamber offers programmable blowing and test times up to 99 h 59 min, a dust-proof 16 A specimen power outlet, and a vacuum interface for connected test samples.
A vertical dust circulation system continuously moves test dust through the workroom, while a vibration-assisted hopper helps prevent talcum powder buildup and supports repeatable exposure conditions. A Nichrome heater dries the circulating powder, and the 7-inch PID programmable touchscreen provides control of temperature, blower, heating, vacuum, testing, and timing, with Ethernet and USB communication for software control and data download. The SUS304 stainless steel interior, tempered viewing windows with dust-resistant sealing, electromagnetic door locks, emergency stop, and multiple electrical safety protections support dependable long-term operation.
Why Choose Labotemp Sand Dust Test Chamber SDC-05?
✓ Controlled Dust Simulation: Vertical circulation and vibration-assisted dust handling improve test consistency.
✓ Advanced Test Control: PID touchscreen, Ethernet, USB, vacuum and programmable test timing.
✓ Built for Long-Term Use: SUS304 interior, electromagnetic locking, viewing windows, and multi-level safety protection.
| No. | Specification | Value |
|---|---|---|
| General Specifications | ||
| 1 | Interior Dimensions (D × W × H) | 2000 × 2000 × 2000 mm |
| 2 | Overall Dimensions (D × W × H) | 2400 × 2550 × 3200 mm |
| 3 | Interior Volume | 8000 L |
| 4 | Door | Two Doors with Two Viewing Windows |
| 5 | Temperature Range | Ambient to +50°C |
| 6 | Humidity Range | <30% RH |
| 7 | Normal Wire Diameter | 50 μm |
| 8 | Nominal Width of Gap Between Wires | 75 μm |
| 9 | Blowing Time | 0 to 99 h 59 min |
| 10 | Test Time | 0 to 99 h 59 min |
| 11 | Power Supply | 220 V, 60 Hz, 1 Phase |
| Dust Testing & Control System | ||
| 12 | Specimen Power Outlet | Dust-Proof Socket, 16 A |
| 13 | Heating Element | Nichrome Heater |
| 14 | Vacuum System | Pressure Gauge, Air Filter, Pressure Regulator, Connecting Tube |
| 15 | Vacuum Sample Interface | Yes |
| 16 | Controller | Programmable Color LCD Touchscreen Controller |
| 17 | Controller Interface | Ethernet, PC Link, USB |
| 18 | View Window Size | 475 × 475 mm |
| 19 | Door Lock | Electromagnetic Lock |
| 20 | Interior Lighting | Built-in Dustproof LED Lighting |
| 21 | Sample Shelf Load Capacity | 50 kg |
| 22 | Mesh Sieve Size | 450 × 450 mm |
| Construction & Safety | ||
| 23 | Exterior Material | A3 Steel Plate with Protective Coating |
| 24 | Interior Material | SUS304 Stainless Steel |
| 25 | Observation Window | Tempered Glass with Double-Layer Thermo-Stability Silicone Rubber Sealing |
| 26 | Standard Configuration | Sample Shelf, Dust Wiper, Talcum Powder 5 kg |
| 27 | Safety Protection | Over-Temperature Protection, Over-Current Protection, Earth Leakage Protection, Phase Sequence Protection |
| 28 | Emergency Stop | Yes |
| 29 | Castors | 4 Adjustable Castors with Brakes |
| 30 | Operating Environment | 5°C to +35°C, ≤85% RH |
| 31 | Maximum Noise | 65 dBA |
| Shipping Dimension | ||
| 32 | Packaging Dimension (D × W × H) | 2600 × 2800 × 3400 mm |
| 33 | Gross Weight | 3Ton |
Electronics & Electrical Equipment Testing:
Evaluates the resistance of electronic devices, electrical components, and enclosures to controlled dust exposure and dust ingress.
Automotive Component Testing:
Supports sand and dust testing of automotive components, assemblies, and equipment designed for demanding environmental conditions.
Military & Defense Equipment:
Used to assess the resistance of military equipment and components to airborne dust and simulated environmental exposure.
Industrial Equipment Testing:
Helps manufacturers evaluate enclosure protection and product durability when equipment is exposed to dusty operating environments.
IP5X & IP6X Testing:
Designed for conducting dust ingress tests based on IEC 60529 and ISO 20653 test methods for suitable products and enclosures.
Large Product & Assembly Testing:
The spacious 8000 L workroom supports testing of large components, assemblies, and multiple specimens under controlled sand and dust conditions.
