Thermal Cycling Chamber LCC-102
Labotemp Thermal Cycling Chamber
Labotemp Thermal Cycling Chamber
Labotemp Thermal Cycling Chamber

Thermal Cycling Chamber LCC-102

Labotemp Thermal Cyclic Chamber LCC-102 is a high-performance environmental test chamber designed for rapid temperature change and thermal cycling applications in electronics, automotive, aerospace, research, and quality control laboratories. Engineered for Environmental Stress Screening (ESS), this thermal cycling chamber delivers precise and repeatable temperature transitions to evaluate material durability, product reliability, and component performance under accelerated environmental conditions. With a 225L chamber capacity and temperature ranges up to -70°C to +150°C, the LCC-102 is suitable for testing electronic assemblies, batteries, polymers, industrial materials, and sensitive components.

Built with a programmable color LCD touchscreen controller, Ethernet connectivity, and PC link functionality, the system offers accurate monitoring and simplified operation for continuous laboratory workflows. The chamber maintains stable testing conditions with ±0.5°C temperature fluctuation and controlled 5°C/min heating and cooling rates for dependable thermal cycling performance. Its mechanical compression refrigeration system ensures energy-efficient operation and long-term reliability, while integrated over-temperature, over-current, refrigerant high-pressure, and earth leakage protection enhance operational safety.

Why Choose Labotemp Thermal Cyclic Chamber LCC-102?

✓ 225L chamber capacity: Suitable for medium-scale environmental testing applications
✓ 5°C/min heating and cooling rate: Supports reliable thermal cycling and ESS testing
✓ Advanced safety protection system: Ensures stable and long-term laboratory operation

$28738
Datasheet
Temperature Performance
Temperature Range -20°C to +150°C (Optional -40°C to +150°C, -70°C to +150°C)
Power Supply 380V / 220V 50Hz
Temperature Fluctuation ±0.5°C
Temperature Deviation ±2.0°C
Cooling Rate 5°C/min
Heating Rate 5°C/min
Control, Safety
Cooling System Mechanical Compression Refrigeration System
Controller Programmable Color LCD Touch Screen Controller with Ethernet Connection and PC Link
Safety Device Over-Temperature Protection, Over-Current Protection, Refrigerant High-Pressure Protection, Earth Leakage Protection
Exterior Material Steel Plate with Protective Coating
Interior Material SUS304 Stainless Steel
Dimension & Shpping
Internal Dimensions (W × D × H) 500 × 600 × 750 mm
Overall Dimensions (W × D × H) 1000 × 1140 × 1870 mm
Interior Volume 225 L
Heat Load 1000 W
Net Weight 395kg
Gross Weight 501kg
Package Size 1270x1180x2120mm
  • ➤ Rapid ESS Testing
  • ➤ Protective-coated steel exterior enhances structural durability in demanding laboratory environments.
  • ➤ Robust cabinet structure minimizes vibration and enhances operational stability.
  • ➤ Precision-engineered chamber ensures repeatable test conditions for quality assurance programs.
  • ➤ Maintains high testing accuracy with ±0.5°C temperature fluctuation and ±2.0°C temperature deviation.
  • ➤ Equipped with comprehensive safety protection against over-temperature, over-current, refrigerant high pressure, and earth leakage.
  • ➤ Integrated internal lighting provides clear visibility of samples throughout the testing process.
  • ➤ Built-in internal drain allows convenient chamber cleaning and simplifies routine maintenance.
  • ➤ Ethernet and PC communication facilitate convenient data management and remote operation.
  • ➤ Heavy-duty construction provides stable performance under intensive laboratory testing conditions.
  • ➤ Well-insulated chamber reduces heat loss and improves overall energy efficiency.
  • Environmental Stress Screening
     Performs rapid thermal cycling to detect early-life failures and improve product reliability
  • Electronics & Battery Testing
     Evaluates electronic assemblies, batteries, sensors, and components under repeated temperature transitions
  • Automotive & Aerospace Validation
     Simulates extreme thermal conditions to verify the durability and performance of critical components
  • Material Testing
     Assesses the thermal stability, expansion, contraction, and fatigue resistance of engineering materials
  • Research & Development
     Supports environmental simulation, product development, and accelerated life testing in laboratories
  • Quality Control
     Verifies product consistency and compliance with reliability and performance standards before production
