Labotemp Vertical Autoclave VEA-04 is a compact 35 liter Automatic Vertical Steam Sterilizer designed for laboratories, research institutes, and small clinical facilities requiring advanced sterilization control. Unlike standard gravity units, this autoclave sterilizer features three-time pre-vacuum technology to enhance air removal and improve steam penetration for wrapped instruments, laboratory glassware, and critical tools. Operating within a temperature range of 116°C to 134°C and a rated working pressure of 0.22 MPa, it delivers stable thermal performance supported by a 3.5 kW heating system for consistent cycle reliability.
Built by an experienced autoclave manufacturer, this model integrates microcomputer automatic control with an LED touch screen for precise parameter management. Automatic water supply, external steam generator, cold air discharge, and automatic exhaust optimize efficiency while reducing manual intervention. Safety interlocking, over-temperature protection, over-pressure self-discharge, and low water level safeguards ensure secure operation. Its energy-efficient design and durable stainless steel chamber support long-term daily laboratory use with dependable performance.
Why Choose Labotemp Vertical Autoclave VEA-04
✓ Three-Time Pre-Vacuum: Improved steam penetration for reliable sterilization of wrapped and complex loads
✓ Intelligent Automation: LED touch control with automatic water and steam management for simplified operation
✓ Engineered for Reliability: Stable temperature control and multi-layer safety protection for consistent long-term use
| No. | Specification | Value |
|---|---|---|
| General Specifications | ||
| 1 | Volume | 35 L |
| 2 | Working Temperature | 134°C |
| 3 | Power | 3.5 kW |
| 4 | Voltage | AC 220 V, 50 Hz |
| Sterilization Parameters | ||
| 5 | Design Temperature | 139°C |
| 6 | Sterilization Temperature Setting Range | 116°C–134°C |
| 7 | Design Pressure | 0.25 MPa |
| 8 | Rated Working Pressure | 0.22 MPa |
| Chamber Dimensions | ||
| 9 | Chamber Size | 350 × 400 |
| 10 | Bucket Dimension | 330 × 320 |
| 11 | Basket Dimension | 320 × 350 |
| Operation | ||
| 12 | Air Removal | Vacuum pump |
| 13 | Automatic Water Filling | Automatic water (standard) |
| Physical Dimensions | ||
| 14 | Outer Dimension (L × W × H) | 696 × 496 × 940 |
| 15 | Packing Size (L × W × H) | 790 × 610 × 1130 |
| 16 | Gross Weight | 130 kg |
| 17 | Net Weight | 115 kg |
Hospitals & Clinical Facilities: Suitable for sterilizing compatible surgical, dental, medical, and laboratory instruments requiring reliable steam penetration.
Pharmaceutical Laboratories: Supports sterilization of compatible laboratory glassware, instruments, containers, and other heat- and moisture-resistant materials.
Research Laboratories: Suitable for sterilizing laboratory instruments, glassware, culture-related materials, and reusable equipment.
Dental Applications: Suitable for compatible hollow, porous, wrapped, and complex dental instruments requiring effective steam penetration.
Medical & Surgical Instruments: Three-time pre-vacuum operation helps improve air removal and steam penetration for suitable wrapped and complex instrument loads.
Microbiology Laboratories: Suitable for compatible glassware, instruments, culture materials, and laboratory items used in routine microbiological workflows.
Laboratory & Academic Facilities: Compact 35 L capacity provides practical steam sterilization for laboratories where space and reliable automatic operation are important.
Porous & Wrapped Loads: Pre-vacuum technology makes the unit suitable for compatible porous, wrapped, hollow, and complex loads requiring improved steam penetration.
